Hiding Linux Processes with Bind Mounts

If you have the privilege to pull off bind-mounting on top of a particular process directory in /proc you should also be able to mount something on top of /proc itself that will present a false /proc/mounts and conceal your trickery. I experimented a bit and wasn't able to bind a single file on top of /proc/mounts and I seem to be having trouble getting procfs to participate in an overlayfs, but if you were really dedicated you could construct a whole fake /proc by hand, or create something using FUSE to create a /proc that redacts anything you want, including mountpoints.

If you're relying on such superficial disguising, just put your process name in brackets directly, no mount privileges required.

As a general rule, if malware gets root privilege, no other process on the same system (container, at least) should be expected to be able to detect it.

I'm so old I remember when ps would directly get the processes via system calls to the kernel and none of this reading from /proc.

The abstraction of representing everything as files is often leaky (and often clunky).

What I want to hide is mounts. With containers, snap (squashfs), etc., the number of mounts on a modern Linux system is growing to ridiculous numbers. And why should they all be visible to normal users?

Coincidentally, I just used a veritable litany of bind mounts this week. I did not attempt to hide anything, though one of those bind mounts exists in order to fake something. I needed this to be able to properly run some x86 software under Rosetta 2 in an arm64 Ubuntu VM.

I wasn't happy with how handling packages for multiple architectures seems to work in Ubuntu/Debian: It looks like you basically have to choose what package you want to install with each architecture, because if you try to install a package for both architectures, they almost always conflict with each other (trying to occupy the same files).

So instead, I made an x86 chroot. I used "debootstrap" to populate the x86 chroot with an x86 Ubuntu base system, and schroot so that a regular non-root user could use that chroot. That way, I can install any x86 package I want without conflicting with the surrounding VM by just chroot'ing into it and regularly typing e.g. "apt install emacs".

But both because a lot of software needs it, and for interop with the surrounding VM (unix domain sockets etc.), I had to create a bunch of bind mounts to bring shared "state" directories into the x86 chroot:

    mount --make-private --bind /proc /data/x86/proc
    mount --make-private --bind /proc /data/x86/sys
    ...

I did this for at least /proc, /sys, /run, /dev, /dev/pts and /home. Depending on how much you want to bring the environments together, you could also add /run, /tmp, and others.

I also added bind mounts for individual files:

   mount --make-private --bind /etc/passwd /data/x86/etc/passwd
   mount --make-private --bind /etc/shadow /data/x86/etc/shadow
   mount --make-private --bind /etc/group /data/x86/etc/group

so that my x86 environment has the same user/group database.

Finally, and I think this is the most interesting piece, some x86 software I tried to run did not work because it tried to parse /proc/cpuinfo for some x86 CPU features. Rosetta 2 implements those, but of course /proc/cpuinfo in the system describes the actual (virtualized) ARM CPUs, which is of course not what x86 software expects.

So, I crafted my own fake cpuinfo text file that looked roughly like it would look in a real x86 environment (I did not put much effort in it, just copied an output from a random real x86 machine and adjusted the number of CPUs), and bind mounted that into the x86 /proc overlay:

   mount --make-private --bind /data/fake-x86-cpuinfo.txt /data/x86/proc/cpuinfo

Now, /proc/cpuinfo inside the chroot (so, /data/x86/proc/cpuinfo) would give the fake cpuinfo and make the x86 software that parses it happy. This is also where the --make-private that I applied to /data/x86/proc earlier becomes important: Without that, that last command would not just overlay /data/x86/proc/cpuinfo, but also /proc/cpuinfo itself, now in turn making arm64 software potentially unhappy. With --make-private on the /proc bind mount, it effectively becomes a separate filesystem in that regard (only).

Finally, the biggest hurdle I had was getting systemd to properly mount all of these in the right order at startup. systemd parallelizes the mounts in fstab (and mounts generally). But if e.g. the /data/x86/proc mount does not happen after both /proc and /data/x86 have been mounted already, you effectively get an empty directory (you can easily work out yourself why that results in all improper cases). This was even more complicated because I use ZFS, and so /data/x86 gets mounted by zfs.mount-service. After much fiddling, I gave up. No combination of "x-systemd.requires=<mountpoint>", "x-systemd.after=zfs-mount.service" and whatever else in the fstab options really fully did the right thing.

I resorted to having a shell script that just runs the bind mounts in the correct order.

in Linux you can rename your own process name, many applications do that to name their threads or to describe what they are doing

isn't it just much easier to rename our process to looks like kernel thread or some other process? we could easily escape process tree by forking child and exiting parent (we would get adopted by init)

Interesting but

>> My guess is that nobody is going to notice this unless they are specifically looking for this technique.

But having two identical PIDs is a pretty weak cloak. Even more so when reducing terminal clutter e.g. run "ps | grep procname" ... anyone not completely asleep is bound to notice it.

If you're looking for naughty processes you could start with:

    mkdir /tmp/foo
    mount -t proc none /tmp/foo
